K-45 4.5 Ton Diesel Forklift

Product Overview

The K-45 4.5 Ton Diesel Forklift is designed for operations that require more load capacity than a standard 4 ton machine while retaining a practical counterbalanced layout. It is suitable for industrial yards, warehouses and factory material transfer.

Available Models

This product page covers CPC45. Select the required model according to the load capacity, load center, working aisle, fork size and engine requirements.

Key Features

4.5 Ton Rated Capacity: The CPC45 / K-45 reference configuration is rated for 4,500 kg at a 500 mm load center.
Wide-View Mast: The mast structure helps improve forward visibility during pallet engagement and placement.
Adjustable Steering Column: The steering-column mechanism supports a more comfortable operator position.
High-Position Air Intake: The intake arrangement helps reduce dust exposure around the engine.
Digital Instrument Panel: A clear display helps the operator monitor forklift status.
Durable Steering Axle Option: A cast steering-axle option can be selected for practical long-term service.

Typical Applications

Factory material transfer and production-line support
Warehouse pallet handling and loading-bay work
Truck and container loading or unloading
Industrial yards, distribution centers and building-material handling

Optional Configurations

Side Shifter: Hydraulic side-shift attachment for faster and more accurate pallet positioning.
Fork Positioner: Hydraulic fork-spacing adjustment for different pallet and load widths.
Duplex, Triplex or Full-Free Mast: Mast configuration and lifting height can be selected according to the warehouse, container and stacking requirements.
Solid Tires: Puncture-resistant tire option for intensive industrial yards and sites with sharp debris.
Semi-Enclosed or Fully Enclosed Cab: Weather-protection options for rain, dust, cold and outdoor operation.
Custom Fork Length: Fork length and section can be configured according to the load dimensions and working conditions.
Engine and Emission Configuration: Engine model and emission configuration are confirmed according to the destination market and quotation.

Quotation Information

Please specify the required model, rated load, lifting height, fork length, tire type, attachment, engine or emission requirement and destination country. Final dimensions and configuration should be confirmed in the formal quotation. Technical values on this page are based on the supplied product catalog. Final specifications may vary with the selected mast, attachment, tire, engine and destination-market configuration.

Quick Info

Model Series: CPC45 / K-45
Rated Capacity: 4.5 Ton / 4500 kg
Lift Height: Custom mast heights available; confirm the required lift height
Fork Length: 1070 mm standard; custom length available
Mast Type: Duplex Mast, Triplex Mast, Full Free Mast
Tire Type: Pneumatic Tire, Solid Tire

Get a Quote

Technical Data

Technical Specifications

Specification	Value	Unit
Rated Capacity	CPC45: 4500	kg
Load Center Distance	CPC45: 500	mm
Free Lift Height	CPC45: 160	mm
Overall Length (With Fork / Without Fork)	CPC45: 4120 / 3050	mm
Width	CPC45: 1400	mm
Overhead Guard Height	CPC45: 2230	mm
Wheelbase	CPC45: 1900	mm
Minimum Ground Clearance	CPC45: 150	mm
Mast Tilt (Front / Rear)	CPC45: 6 / 12	degree
Front Tire	CPC45: 300-15-20PR
Rear Tire	CPC45: 7.00-12-12PR
Minimum Turning Radius	CPC45: 2820	mm
Minimum Right-Angle Aisle Width	CPC45: 4830	mm
Fork Size	CPC45: 1070×150×50	mm
Maximum Working Speed (Full Load / No Load)	CPC45: 18 / 19	km/h
Maximum Lifting Speed (Full Load / No Load)	CPC45: 420 / 460	mm/s
Maximum Gradeability (Full Load / No Load)	CPC45: 15 / 20	%
Forklift Weight	CPC45: 5860	kg
Engine Model	CPC45: Quanchai 4C4-50V31

* Specifications may vary. Contact us for customized configurations.

Why Choose This Model

Key Features

01

4.5 Ton Rated Capacity

The CPC45 / K-45 reference configuration is rated for 4,500 kg at a 500 mm load center.

02

Wide-View Mast

The mast structure helps improve forward visibility during pallet engagement and placement.

03

Adjustable Steering Column

The steering-column mechanism supports a more comfortable operator position.

04

High-Position Air Intake

The intake arrangement helps reduce dust exposure around the engine.

05

Digital Instrument Panel

A clear display helps the operator monitor forklift status.

06

Durable Steering Axle Option

A cast steering-axle option can be selected for practical long-term service.

Customization

Optional Configurations

Customize this model to fit your specific working conditions and requirements.

Side Shifter

Hydraulic side-shift attachment for faster and more accurate pallet positioning.

Fork Positioner

Hydraulic fork-spacing adjustment for different pallet and load widths.

Duplex, Triplex or Full-Free Mast

Mast configuration and lifting height can be selected according to the warehouse, container and stacking requirements.

Solid Tires

Puncture-resistant tire option for intensive industrial yards and sites with sharp debris.

Semi-Enclosed or Fully Enclosed Cab

Weather-protection options for rain, dust, cold and outdoor operation.

Custom Fork Length

Fork length and section can be configured according to the load dimensions and working conditions.

Engine and Emission Configuration

Engine model and emission configuration are confirmed according to the destination market and quotation.

Ask About Custom Configurations

Common Questions

Frequently Asked Questions

How do I choose the right diesel forklift capacity?

Select a rated capacity above the actual load weight and confirm the load-center distance. Mast height, attachments and long loads can reduce residual capacity, so the final configuration should be checked before ordering.

What mast heights and attachments are available for diesel forklifts?

Common options include duplex, triplex and full-free masts, side shifters, fork positioners, longer forks and enclosed cabs. Availability depends on the selected model and required residual capacity.

Which engine options are available for diesel forklifts?

Engine model and emission configuration depend on the forklift series, destination market and local requirements. The exact engine is confirmed in the formal quotation.

Can diesel forklifts be used indoors?

Diesel forklifts are mainly suited to outdoor or well-ventilated industrial areas. For indoor work, confirm ventilation, emission rules, noise limits, aisle width and mast-clearance requirements.

What information is needed for a diesel forklift quotation?

Please provide the required load capacity, load center, lifting height, fork length, tire type, attachment, engine or emission requirement, operating environment and destination country.
